Operation Manual SUPREMA
5. Installation
1 / 3
1-8
Position: Position No. of the slot in the rack
Rack: No. of the rack in which the module is installed.
Nos. of the connected inputs and outputs.
2 / 9
1-40
Rack: Serial No. of the rack to which the module is connected via a ribbon cable
and a MUT module (or a MRC-TS and a MUT module)
Serial Nos. of the connected inputs and outputs
Position: Position No. of the slot in the rack to which the module is connected
via a ribbon cable and a MUT module (or a MRC-TS and a MUT module) ist.
Figure 5-49 shows a possible labelling system.
Figure 5-49: Labelling of the connection and terminal modules in the rack
5.12.4 Connection and Terminal Modules in Rail-Mounted Installation
A free labelling field is provided for modules installed on mounting rails (MRO-8-TS, MAT-TS,
MRC-TS, and MGT-40-TS modules). Figure 5-50 shows a possible labelling system.
Figure 5-50: Labelling of the rail-mounted connection and terminal modules
5.12.5 MAT(-TS) Connector Plug
A free labelling field is provided on the bottom of the connector plug of the MAT and MAT-TS
modules. Figure 5-51 shows a possible labelling system.
1 / 1
1
Position: No. of the slot of the MAT-(TS) module on the rack
Rack: No. of the rack on which the MAT-(TS) module ist mounted
Nos. of the connected inputs and outputs
Figure 5-51: Labelling of the MAT-(TS) connector plug
