1. General Information
1.2 Sensors Which Can Be Connected to the Unit
The following types of active and passive MSA sensors can be connected to the SUPREMA
system:
Table 1-1:
Sensors
available for
connection
(EX: Explosive gases or vapors; TOX: Toxic gases; OX: Oxygen; Fire Detection: Smoldering
Fire Detection; Flame: Flame Detector)
* With regard to fire and smoke detection, the SUPREMA has not been evaluated to any Canadian standard by
a third party agency.
Designation Module Measuring Use Active Passive
Type Principle
DF-7100 MCI catalytic EX X
DF-7010 MCI catalytic EX X
DF-9500 MCI electrochemical TOX/OX X
DF-9200 MCI electrochemical TOX/OX X
DF-8510 MCI electrochemical Fire Detection* X
DF-8501 MCI semiconductor Fire Detection* X
DF-8502 MCI semiconductor Fire Detection* X
DF-8401 MCI semiconductor TOX X
DF-8603 MCI semiconductor TOX X
DF-8201 MCI semiconductor TOX X
DF-8250 MCI semiconductor EX X
GD10 MCI infrared EX X
SafEye 2 and 4 MCI infrated/ultraviolet EX/TOX X
IR-3600 MCI infrared CO
2
X
D-7010 MPI-WT10 catalytic EX X
D-7100 MPI-WT100 catalytic EX X
D-7600 MPI-WT100 catalytic EX X
D-7602 MPI-WT100 catalytic EX X
D-7606 MPI-WT100 catalytic EX X
D-7400 MPI-WT100 catalytic EX X
D-7711 MPI-WT100 catalytic EX X
D-715 MPI-WT100 catalytic EX X
D-7152 MPI-WT100 catalytic EX X
Series 47K MPI-WT100 catalytic EX X
D-8101 MPI-HL8101 semiconductor TOX/EX X
D-8113 MPI-HL8113 semiconductor TOX/EX X
D-8201 MPI-HL8101 semiconductor TOX/EX X
D-8213 MPI-HL8113 semiconductor TOX/EX X
Type 410 MPI-WT100 catalytic EX X
Type 451 MCI electrochemical TOX X
Ultima MCI EX X
Ultima IR MCI infrared EX X
Ultima XE MCI catalytic EX X
Ultima X IR MCI infrared EX X
FlameGard MCI infrared Flame* X
