MSA SUPREMA - Figure 5-32: MRO-8 Module, Terminal Assignment; Table 5-25: MRO-8 Module, Terminal Assignment

REV 0, June 2005Page 140
Operation Manual SUPREMA
5. Installation
MRO-8 Module, Relay Assignment
Table 5-25: MRO-8 Module, Terminal Assignment
Relay No. Terminal No. Contac
t
11NO
2C
3NC
213NO
14 C
15 NC
34NO
5C
6NC
416NO
17 C
18 NC
57NO
8C
9NC
619NO
20 C
21 NC
710NO
11 C
12 NC
822NO
23 C
24 NC
Figure 5-32: MRO-8 Module, Terminal Assignment
