REV 0, June 2005Page 226
Operation Manual SUPREMA
10. Redundant Systems
pressed for approx. 1 sec. during warm-up. The system configuration message appears after
the warm-up period, so that the configuration can be taken from this module.
• Switch off system, connect all additional modules
• Switch on system (new startup)
During the warm-up period, the following message appears on the front panel display (MDO
Module):
AUER-SUPREMA-MDO-XX
Rev. xxxxxxx HW xxx
Figure 10-6: Startup Message
Note: As of version 1.02.07, automatic reading-in of the configuration is no longer
possible. The configuration must always be generated and transferred manually.
During this message, the RESET button has to be pressed for approx. 1 sec. After segment
test of the display, the following message appears:
System configuration
There are several possible system configu-
rations available, please select the
configuration to be used
Module ID Configuration name
——————————————————
[OK]
Figure 10-7: System Configuration Message
By pressing the cursor keys, the operator can select the MCP card which contains the valid
system configuration. By pressing the OK button, the configuration selected will be copied to
the other MCP modules and to the MDO.
Attention: When selecting “recognised parameters deleted” the measuring point
parameters are completely deleted, and a new configuration is generated
automatically by reading the system configuration. I.e. all measuring point
parameters must be entered once more.
After this, the system has to be started up once more by switching off and on. During the warm-
up period of the system, the current hardware configuration is compared with the configuration
listing stored. If there are differences, a system failure message will appear.
In the case of retrofitting, a new configuration of the system is not necessary.
