Table 5-2: Cable Specifications
Type of Number of Cable Max. cable loop resis- Maximum Remarks
Sensor Wires Type tance in ohms (xxx*) => Length
for 4 ... 20 mA Zone
max. working resistance
D-7600 5 x 0.75 mm² Y(C)Y 36 ohms 750 m Screened cable is required
.
D-7602 5 x 1.5 mm² Y(C)Y 36 ohms 1500 m
D-715
D-7152
D-7711
D-7100
Series 47K
D-7010 5 x 0.75 mm² Y(C)Y 28 ohms 500 m Screened cable is required
.
5 x 1.5 mm² Y(C)Y 28 ohms 1000 m
D-7600 3 x 0.75 mm² Y(C)Y 36 ohms 750 m Screened cable is required
.
D-7602 3 x 1.5 mm² Y(C)Y 36 ohms 1500 m
D-715
D-7152
D-7711
D-7100
Series 47K
D-7010 3 x 0.75 mm² Y(C)Y 28 ohms 500 m Screened cable is required
.
3 x 1.5 mm² Y(C)Y 28 ohms 1000 m
D-8101 4 x 1.5 mm² Y(C)Y 36 ohms 1500 m Screened cable is required
.
D-8113
D-8201
D-8213
DF-9500 2 x 1.5 mm² NYSLYCYÖ 500 ohms (100 ohms) 20000 m Screened cable is required
.
DF-9200 (CY(Ex)i) (4000 m) The values in parentheses
apply only to the DF-9500
in association with zener
barriers (operation in explo-
sive area, cable color blue)
.
Follow the instructions the
use of zener barriers or
galvanic isolators. Zener
barriers and galvanic isola-
tors must be installed out-
side the hazardous area.
DF-7010 3 x 1.5 mm² Y(C)Y 20 1000 m Screened cable is required
.
DF-7100
DF-8603
DF-8201 3 x 1.5 mm² Y(C)Y Screened cable is required
.
DF-8250
DF-8401 3 x 1.5 mm² Y(C)Y 20 1000 m Screened cable is required
.
DF-8501*
DF-8502*
DF-8510* 2 x 1.5 mm² Y(C)Y 200 ohms 1000 m Screened cable is required
.
GD10 3 x 1.5 mm² Y(C)Y 20 840 m Screened cable is required
.
SafEye 4 x 1.5 mm² Y(C)Y 10 420 m Screened cable is required
.
Ultima X 2 x 0.5 mm² Y(C)Y 2000 m Screened cable is required
.
2 wire
Ultima X 3 x 0.5 mm² Y(C)Y 300 m Screened cable is required
.
3 wire 3 x 1.0 mm² 750 m
3 x 1.5 mm² 1250 m
* With regard to fire and smoke detection, the SUPREMA has not been
evaluated to any Canadian standard by a third party agency.
