MSA SUPREMA - Table 5-26: MRO-8-TS Module, Common Alarm Relay Assignment; Table 5-27: MRO-8-TS-Module, Terminal Assignment

REV 0, June 2005 Page 143
Operation Manual SUPREMA
5. Installation
Table 5-26: MRO-8-TS Module, Common Alarm Relay Assignment
Relay No. Assignment
11st Alarm
2 2nd Alarm
33rd Alarm
4 4th Alarm
5 Signal Failure (Sensor)
6Horn
7 Inhibit
8 Power Supply Failure
Relay No. Terminal No. Contac
t
11NO
2C
3NC
213NO
14 C
15 NC
34NO
5C
6NC
416NO
17 C
18 NC
57NO
8C
9NC
619NO
20 C
21 NC
710NO
11 C
12 NC
822NO
23 C
24 NC
MRO-8-TS module
The terminals are assigned as follows:
Table 5-27: MRO-8-TS-Module, Terminal Assignment
