Operation Manual SUPREMA
12. Sensor Data Sheets
Open or short-circuit fault indication at the following configuration:
S101: 1 and 2 = ON; 3 and 4 = OFF (External power supply)
S102: 1 and 2 = ON; 3 and 4 = OFF (Contact type NO)
S103: 3 and 4 = ON (overall line control)
X = Signal failure (FAIL) XX = Signal - Alarm N = Failure case has no effect
Short-circuit at the Wire Wire Wire Wire Wire Wire
MAT-(TS)-Module -X1/1 -X1/1 -X1/1 -X2/4 -X2/5 -X4/5
with with with
-X1/2 -X1/4 -X1/5
Failure indication X X N X X X
Short-circuit at Wire Wire Wire Wire Wire Wire
max. Leitungslänge -X1/1 -X1/1 -X1/1 -X2/4 -X2/5 -X4/5
with with with
-X1/2 -X1/4 -X1/5
Failure indication X X N X X X
Open-circuit at max. Wire Wire Wire Wire
cable length -X1/1 -X1/2 -X1/4 -X1/4
Failure indication X X X X
Open-circuit at the Wire Wire Wire Wire Disconnect plug
MAT-(TS)-Module -X1/1 -X1/2 -X1/4 -X1/5 of MAT-(TS)
Failure indication X X X X X
