Example of the Hyperterminal for Windows:
The Null modem line must be connected to the CAN bridge CBM (X100), and the Computer
COM Port. The terminal program must be started with the a.m. settings.
After switching on the CAN bridge, the start screen on the terminal display looks like that
shown below, or similar.
.........................=============================
> > > R T O S - U H < < <
=============================
Nuc=7.8-A Daemon=2.3 EdFm=2.L Vi/Vo=1.6 assign=0.9
Math=1.H Hyp=15.4-J R/W_P90=1.6 Dat1.4 Dev = 3.5
IDF=1.1 Prom=3.0 Editor 10.B Help=1.F Sh/sr=4.7-C
sh/ext=1.2x Shell=4.4-D XC 4.2-L Loader=6.5-F copy=1.H
ScAcc=1.3 User=0.8 I/O_Pack=25 DBV/rw=1.1 Nil=1.2
Extp=4.3A Setup=3.3e SysRes=15c EX=2.2-M Check=1.5
CBM-DP_Ini=2.5 Imp/CBM_S=5.8C T_IrLk=1.0 Flash_Prom=0.P
SRamDsk=1.8g
Fm=UHFM3.J LineEd-F=1.3G
RESET.
C200I:Using I/O-Base 0x800000 for card 0ADRS_00200000 Flash_Prom
1*AMD29
F080
CPU-Type_68331 25.2_MHz Date_-------- Time_00:00:00
C200I: Using Interrupt 30 for card 0
C200I: Using Interrupt 30 for card 0
C200I: ’’CAN_SJA100’’ with 2 Nets identified
C200I: Hardware-Version=1.0.00
C200I: Firmware-Version=0.0.00
Command R and >Enter<, will get the current parameters:
V1.3
>r
B0:6
B1:6
This is the contents for a reset CAN bridge; both baud rates are set to 125k. Before programming
all parameters in the CAN-Bridge must be delete.
When the *.txt file generated above is transferred with help of the terminal program, the following
screen contents will be seen:
>B0:6
>I0:0 I1:0
>I0:80 I1:80
>I0:100 I1:100
>I0:614 I1:614
>I0:714 I1:714
>I0:21E I1:21E
>I0:61E I1:61E
>I0:71E I1:71E
>B1:9
>M1:0:0xxxxxxxxxxxxxxxxxxxxxxxxxxxxx
