Operation Manual SUPREMA
12. Sensor Data Sheets
Simulation of normal operation / Alarm / RESET / Open or short-circuit fault indication:
Simulation Effect
Normal operation
External power supply 23 ... 32 V Normal operation
connected according to circuit diagram
END OF LINE resistor 2K2
connected according to circuit diagram
Connect resistor 10 K 0.5 W Voltage of terminal 1–2 shall be <0.1 V
between terminal 1 and 2
Alarm
External power supply 23 ... 32 V
connected according to circuit diagram
END OF LINE resistor 2K2
connected according to circuit diagram
Connect resistor 1.0 K 1 % 0.5 W Alarm message
between terminal 3 and 4
RESET
Connect wire jumper between terminals 3 and 4 Normal operation
After max. 45 s failure message appears.
Open-circuit of line
External power supply 23 ... 32 V
connected according to circuit diagram
END OF LINE resistor 2K2 not connected Failure message
Line short-circuit
External power supply 23 ... 32 V
connected according to circuit diagram
END OF LINE resistor short-circuited Failure message after max. 45 s
Interruption of the supply voltage
External power supply 23 ... 32 V Failure message
not connected
END OF LINE resistor 2K2
connected according to circuit diagram
Leakage current
External power supply 23 ... 32 V
connected according to circuit diagram
END OF LINE resistor 2K2
connected according to circuit diagram
Connect resistor 10 K 0.5 W
between terminal 1 and 2
Connect resistor 18 K between terminals 4 and Failure message
5, or connect resistor 330R between terminals Voltage terminal 1–2 must be 23 ... 32 V
3 and 5.
* With regard to fire and smoke detection, the SUPREMA has not been evaluated to any Canadian standard by
a third party agency.
