Operation Manual SUPREMA
4. Operation of the System
After an output number is selected, the rest of the menu is filled, if settings have already been
entered for that output. This input field can be accessed without a key switch or password if an
output is entered for which parameters have already been set. If a number is entered that has
not been used before, authorisation by means of password or key switch is required.
This makes it easy to copy the settings from one input to another. If an input is displayed that
has not yet been configured, default values are use as the preliminary settings for the input of
the certain fields.
This selection field can be accessed without a key switch or password if an input is entered for
which input parameters have already been set. If a number is entered that has not been used
before, authorisation by means of password or key switch is required.
All parameter changes using the menu items described below apply to the selected
relay outputs in that field.
Normaly energised/Normaly de-energised
Field type: Selection
Set the operating mode for the selected relay output:
Normaly energised:
The relay output delivers in the set-condition (Alarm, Failure) a LOW-Signal, this is called a
connected relay is not energised. (The Normaly energised principle)
Normaly de-energised:
The relay output delivers in the set-condition (Alarm, Failure) a HIGH-Signal, this is called a
connected relay is energised. (The Normaly de-energised principle)
Tag
Field type: text
Enter a customer-specific designation for the selected relay output.
New Alarm (i. e. actual alarm)
Field type: Check boxes
If this field is set, the relay output selected can be set to “normal” status by pressing the <ACKNL>
key in spite of the value having been outside the limits.
Ï, Ð
Field type: Button
These buttons are used by the operator to select the required portion of the displayed
configuration matrix. In the configuration matrix, it is possible to set the conditions for each
input (1
st
to 4
th
alarms, Fail, Lock) that must be met for the selected relay output to be activated.
Chan. (Channel)
Field type: Selection field
The field contains a list of all configured inputs. When opened, it contains the input that was
last selected in the Measure Point menu. The following conditions, which must be met in order
to set the relay output selected in the “Relay” field, apply to the input displayed here.
