Setting example
Exam
ple 1
S3 “INITIAL”
Settings
Maximum size: 100, Timeout period: 60 seconds, Number of retries: 3, Retry interval: 600
seconds, Language: Japanese
Exam
ple 2
S3 “KEEP”
Settings
Maximum size: Not change, Timeout period: Not change, Number of retries: Not change, Retry
interval: Not change,
Language: Not change
■
Flag operations
Name Description
SR7
SR8
(ER)
Set when a value outside the range is specified for the parameter.
Set when the same keyword is specified redundantly.
To be set when even one request active relay of mail transmission control relay or mail
transmission logging/trace control relay is 1: Requesting.
To be set when "Add-on" is set to "Not use" in Built-in ET-LAN setting.
To be set when the slot number [S1] specified with UNITSEL is not 100 (built-in ET-LAN).
Set when executed in an interrupt program.
Set when the number of characters for operand specifying character constant exceeds 256.
CY
(SR9)
To be set when the instruction is executed with an incorrect IP address. The detail code set in
SD29 is "1: Specification of incorrect IP address".
Set when the instruction is the initialization of Ethernet. The detail code set in SD29 is "11:
Ethernet initialization active".
(Note 1) For details of the error codes stored in the system data SD29, refer to "20.2 List of System Data
Registers".
17.22 SMTPcSV (Mail Server Setting)
17-114 WUME-FP7CPUPGR-12
