Name Description
To be set when [D1] (offset position) exceeds the value of the 1st word (total number of data)
of [S1] (CIP message) before processing.
To be set when [D1] (offset position) exceeds the value of the 1st word (total number of data)
of [S1] (CIP message) after processing.
■
CIP status codes
Status code Status name Description
0x00 Success Execution of the service by the specified object was successful.
0x01 Communications
Related Problem
A connection-related service was unsuccessful along the connection
path.
0x02 Resource unavailable The resources required for the object to perform the requested
service were not available.
0x03 Invalid parameter
value
To select the correct value for this condition, refer to Status Code 20
(hexadecimal number).
0x04 Path segment error The path segment identifier or segment syntax was not interpreted
by the processing node. Path processing is stopped if an error
occurs in the path segment.
0x05 Path destination
unknown
The path references an object class, instance, or structural element
that is not identified or contained in the processing node. Path
processing is stopped if a path destination unknown error occurs.
0x06 Partial transfer Only part of the expected data was transferred.
0x07 Connection lost The messaging connection was interrupted.
0x08 Service not supported The requested service was not implemented. Or, it was not defined
for this object class/instance.
0x09 Invalid attribute value Invalid attribute data was detected.
0x0A Attribute list error An attribute in the Get_Attribute_List or Set_Attribute_List response
has a non-zero status.
0x0B Already in requested
mode/state
The object is already in the mode/state being requested by the
service.
0x0C Object state conflict The object cannot perform the requested service in the current
mode/state.
0x0D Object already exists The requested instance of the object to be created already exists.
0x0E Attribute not settable A request to modify a non-modifiable attribute was received.
0x0F Privilege violation A permission/privilege verification was unsuccessful.
0x10 Device state conflict The device cannot perform the requested service in the current
mode/state.
0x11 Reply data too large The data transmitted in the response buffer is larger than the
allocated response buffer.
0x12 Fragmentation of a
primitive value
The service specified an operation that is going to fragment a
primitive data value, i.e. half a REAL data type.
0x13 Not enough data The service did not supply enough data to perform the specified
operation.
0x14 Attribute not supported The attribute specified in the request is not supported
0x15 Too much data The service supplied more data than was expected.
17.34 CIPMGET (CIP Message Data Getting)
WUME-FP7CPUPGR-12 17-177
