Page #863 background imageLoading...
Page #863 background image
Available bit devices (●: Available)
Operand
Bit device
Specification of bit of
word device
Index
modifier
X Y R L T C P E SR IN OT DT.n LD.n
S
n
D1
D2
(Note 1)
D3
(Note 1) When the receiver is FP7, only global devices can be specified. (A local device cannot be specified.)
Outline of operation
Data can be transferred from the master unit to the partner unit between PLCs connected by
MEWNET-W or MEWNET-W2.
When the SEND instruction is executed, the data is read from the device that starts with [S]
in the master unit and the data is stored in the address that starts with [D2] in the partner
unit.
Setting the amount of sent data [n]
Transfer method Communication Mode Amount of sent data n
Register transfer
W mode 1 to 55 words
W2 mode 1 to 1020 words
Bit transfer
W mode Fixed at 1 bit
W2 mode Fixed at 1 bit
(Note 1) The transfer method varies according to the device type specified for operands [S] and [D2]. The
register transfer is used for 16-bit devices and the bit transfer is used for 1-bit devices.
Devices specified for [S] and [D2] Transfer method
16-bit device: WX, WY, WR, WL, DT, LD
Register
transmission
1-bit device: X, Y, R, L, DT.n, LD.n Bit transmission
(Note 2) The amount of sent data is specified in words for the register transfer and in bits for the bit transfer.
Specification of partner unit station number [D1]
Communication Mode Setting range
W mode 1 to 32
W2 mode 1 to 64
Specification of destination address [D2]
Transfer method Communication Mode Address range
Register transfer
W mode
0 to 65535
16.1 SEND (When FP7 Multi-wire Link Unit Is Used)
WUME-FP7CPUPGR-12 16-3
