Value Description
-DT15
DT16
-DT23
-
When [Automatically acquire IPv6 address] - [Acquire from router] is selected, the
master unit IPv6 address is stored. For manual setting, "0" is stored.
DT24
-DT31
-
When [Automatically acquire IPv6 address] - [Acquire from DHCP] is selected,
the master unit IPv6 address is stored. For manual setting, "0" is stored.
DT32 H0100 (U64)
The subnet prefix length is stored.
Example) 64
DT33 HFE80
The Ipv6 address of the default gateway is stored.
Example) fe80::1
DT34 H0000
DT35 H0000
DT36 H0000
DT37 H0000
DT38 H0000
DT39 H0000
DT40 H0001
DT41 HAABB
The MAC address of the destination unit is stored.
Example) AA-BB-CC-DD-EE-FF
DT42 HCCDD
DT43 HEEFF
Example 5) When specifying the destination port number for a specified IPv4
connection
The results are stored in the 19-word area that starts with [D].
[S1]... "IPv4" [S2]... "CONNECT1" [D]...DT20
Value Description
DT20 H00C0 (U192)
The master unit IPv4 address is stored.
Example) 192.168.5.30
DT21 H00A8 (U168)
DT22 H0005 (U5)
DT23 H001E (U30)
DT24 H00FF (U255)
The subnet mask is stored.
Example) 255.255.255.0
DT25 H00FF (U255)
DT26 H00FF (U255)
DT27 H0000 (U0)
DT28 H00C0 (U192)
Default gateway
Example) 192.168.5.1
DT29 H00A8 (U168)
DT30 H0005 (U5)
DT31 H0001 (U1)
DT32 H9001 The master unit port number is stored.
DT33 H0000 This value indicates the type of the IP address. For IPv4, the value is "0".
DT34 H00C0 (U192)
The destination IPv4 address is stored.
17.2 ETSTAT (Acquiring Ethernet Unit Information: IP/MAC/Destination)
17-12 WUME-FP7CPUPGR-12
