Value Description
DT35
Example) 192.168.5.1
H00A8 (U168)
DT36 H0005 (U5)
DT37 H000B (U11)
DT38 H8001 (U32769)
The destination port number is stored.
Example) 32769
Example 6) When specifying the destination port number for a specified IPv6
connection
The results are stored in the 52-word area that starts with [D].
[S1]... "IPv6" [S2]... "CONNECT1" [D]...DT0
Value Description
DT0 HFE80
The master unit IPv6 address (manual setting) is stored.
Example) fe80:0011:2233:4455:6677:8899:aabb:ccdd
DT1 H0011
DT2 H2233
DT3 H4455
DT4 H6677
DT5 H8899
DT6 HAABB
DT7 HCCDD
DT8
-DT15
- The master unit IPv6 address (link local) is stored.
DT16
-DT23
-
When [Automatically acquire IPv6 address] - [Acquire from router] is selected, the
master unit IPv6 address is stored. For manual setting, "0" is stored.
DT24
-DT31
-
When [Automatically acquire IPv6 address] - [Acquire from DHCP] is selected,
the master unit IPv6 address is stored. For manual setting, "0" is stored.
DT32 H0100 (U64)
The subnet prefix length is stored.
Example) 64
DT33 HFE80
The IPv6 address of the default gateway is stored.
Example) fe80::1
DT34 H0000
DT35 H0000
DT36 H0000
DT37 H0000
DT38 H0000
DT39 H0000
DT40 H0001
DT41 H9001 The master unit port number is stored.
DT42 H0001 The type of the IP address is stored. For IPv6, the value is "1".
DT43 HFE80
The destination IPv6 address is stored.
Example) fe80:0011:2233:4455:6677:8899:99AA:ccdd
DT44 H0011
17.2 ETSTAT (Acquiring Ethernet Unit Information: IP/MAC/Destination)
WUME-FP7CPUPGR-12 17-13
