88C-19
AIR BAG AND PRETENSIONERS
Front side seat belt: Removal - Refitting
88C
a Remove:
-the cover of the seat belt upper bolt,
-the seat belt upper bolt (2) .
a Remove the lower B-pillar trim (see B-pillar trim:
Removal - Refitting) (71A, Body internal trim).
a
Mark the wiring routing at the front side seat belt in-
ertia reel.
a Unclip the inertia reel connector safety clip.
a Disconnect the inertia reel connector.
108515
WITH FRONT PRETENSIONER
101920
WARNING
To prevent any risk of noise, premature wear,
short circuits, etc. after the refitting operation,
mark the wiring routing and how to connect the
connectors.
