80D-17
AFTER REPAIR
Carry out another fault finding check on the system.
Deal with any other faults.
Clear the stored faults.
V1
MR-453-X79-80D000$080.mif
LIGHTING
Fault finding – Interpretation of statuses
80D
UCH
Vdiag No.: 09
ET324
CONTINUED 1
Check between the lighting stalk and the engine fuse and relay box:
Check the continuity and insulation of the following connections:
• BP11 between components 209 and 597,
• BP13 between components 209 and 597,
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
Check for +12 V (when side lights are requested) on the following connection:
• LPG of component 645 for right-hand drive
• LPD of component 645 for left-hand drive
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
Check the continuity and the insulation of the following connections:
• LPG between components 1016 and 645 for right-hand drive
• LPD between components 1016 and 645 for left-hand drive
• L between components 1016 and 209
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
