80D-16
AFTER REPAIR
Carry out another fault finding check on the system.
Deal with any other faults.
Clear the stored faults.
V1
MR-453-X79-80D000$080.mif
LIGHTING
Fault finding – Interpretation of statuses
80D
UCH
Vdiag No.: 09
ET324
SIDE LIGHTS REQUEST
STATUS DEFINITION
PRESENT when the side lights are switched on.
ABSENT if there is no request for the side lights.
NOTES
There must be no present or stored faults.
Move the side lights switch.
The status should be PRESENT and the side lights illuminated.
Special note:
Use the Wiring Diagrams Technical Note for DUSTER.
Check the presence and condition of fuses F18 (10 A) and F19 (10 A) on the passenger compartment fuse box,
component code 1016, and fuses F1 (60 A) and F2 (60 A) on the engine fuse and relay box, component code 597
(see MR 451 Mechanical, 81C, Fuses, Fuses: List and location of components).
Check the connection and the condition of the connector of the engine fuse and relay box, component code 597,
the UCH computer, component code 645, and the lighting stalk, component code 209.
If the connector is faulty and there is a repair procedure (see Technical Note 6015A (Renault) or Technical Note
9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the connector, otherwise replace
the wiring.
Check for +12 V on connections BP13 and BP11 of component 209.
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
UCH_V09_ET324
