80D-26
AFTER REPAIR Carry out a road test, followed by a check with the diagnostic tool.
V1
MR-453-X79-80D000$100.mif
LIGHTING
Fault finding – Interpretation of commands
80D
UCH
Vdiag No.: 09
AC145
FRONT COURTESY LIGHTS
NOTES
This command is used to activate the front courtesy light.
There must be no present or stored faults.
Switch on the ignition.
Special note:
Use the Wiring Diagrams Technical Note for DUSTER.
Check the correct operation of the courtesy light in the ON position and the condition of the front courtesy light bulb,
component code 213. Replace the bulb if necessary (see MR 451 Mechanical, 81B, Interior lighting, Courtesy
light: Removal - Refitting).
Check for +12 V on the front courtesy light, component code 213 on the following connection:
• BPT of component 213.
Check the continuity and insulation of the following connection:
BPT between components 213 and 645.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
UCH_V09_AC145
