80D-27
AFTER REPAIR Carry out a road test, followed by a check with the diagnostic tool.
V1
MR-453-X79-80D000$100.mif
LIGHTING
Fault finding – Interpretation of commands
80D
UCH
Vdiag No.: 09
AC145
CONTINUED
Check for earth on the front courtesy light, component code 213 on the following connection:
• MAM of component 213.
Check the continuity and insulation of the following connection:
MAM between component 213 and earth.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Put the courtesy light in the AUTO position and run command AC145.
Check the continuity, insulation and the absence of interference resistance of the following connection:
• 13A or 13E between components 645 and 213.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault is still present, contact the Techline.
