80D-30
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 2
CONTINUED 1
Side lights check:
Check the continuity and insulation of the following connections:
Front left-hand side light:
• LPG between components 227 and 1016,
• MB between component 227 and earth,
Rear left-hand side light:
• LPG between components 173 and 1016,
• MG between component 173 and earth,
Front right-hand side light:
• LPD between components 226 and 1016,
• MA between component 226 and earth,
To Next Page
