80D-31
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 2
CONTINUED 2
Rear right side light:
• LPD between components 172 and 1016,
• MF between component 172 and earth,
Right-hand number plate light:
• LPD between components 166 and 1016,
• MF between component 166 and earth,
Left-hand number plate light:
• LPD between components 167 and 1016,
• MG between component 167 and earth,
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
If the fault is still present, contact the Techline.
