80D-32
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 3 No dipped headlights
NOTES
Only consult this customer complaint after a full check with the diagnostic tool.
There must be no present or stored faults.
Check the conformity of status ET324 Side lights request.
If not correct, refer to the interpretation of this status.
Special note:
Use the Wiring Diagrams Technical Note for DUSTER.
Put the lighting stalk, component code 209 in the dipped headlights position.
Check the presence and condition of the supply fuse of the left-hand headlight, component code 227:
• F09 (10 A) on component 1016,
Replace the fuse(s) if the checks are not correct (see MR 451 Mechanical, 81C, Fuses, Fuses: List and location
of components).
Check the presence and condition of the supply fuse of the right-hand headlight, component code 226:
• F10 (10 A) on component 1016,
Replace the fuse(s) if the checks are not correct (see MR 451 Mechanical, 81C, Fuses, Fuses: List and location
of components).
Check the condition of the bulbs. Replace the bulbs if they are defective (see MR 451 Mechanical, 80B, Front
lighting: List and location of components).
UCH_V09_ALP3
