80D-33
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 3
CONTINUED 1
Check the condition and connection of the connectors of the left-hand headlight, component code 227, the right-
hand headlight, component code 226, and the lighting stalk, component code 209.
If the connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check for +12 V (when the dipped headlights are requested) on the following connections:
• CPG of component 227,
• CPD of component 226 .
Check for earth on the following connections:
• MB of component 227,
• MA of component 226.
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
