80D-34
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 3
CONTINUED 2
Check the continuity and insulation of the following connections:
• CDO between components 209 and 1016.
Front right-hand dipped beam headlight:
• CPG between components 227 and 1016,
• MB between component 227 and earth,
Front right-hand dipped beam headlight:
• CPD between components 226 and 1016.
• MA between component 226 and earth,
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
With the dipped headlights control activated, check for +12 V on connection CDO of the lighting stalk, component
code 209.
If not correct, replace the lighting stalk (see MR451 Mechanical 84A, Control - Signals, - Lighting - signals
switch: Removal - Refitting)
If the fault is still present, contact the Techline.
