80D-40
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 5
CONTINUED 2
Check for +12 V (when the front fog lights are requested) on the following connections:
• 8A of component 231,
• BP16 of component 231,
Check for earth on the following connection:
• MB of component 231,
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
Front fog lights relay check:
Check the continuity and insulation of the following connections:
• 8A between components 209 and 231,
• BP16 between components 231 and 1016.
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
Check for +12 V on the following connections:
• BP11 of component 209,
• BP13 of component 209,
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
