80D-41
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 5
CONTINUED 3
Check between the lighting stalk and the engine fuse and relay box:
Check the insulation and the continuity of the following connections:
• BP11 between components 209 and 597,
• BP13 between components 209 and 597,
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
If the supplies and the connections are correct, replace the lighting stalk.
If the fault is still present, contact the Techline.
