11A-5
TOP AND FRONT OF ENGINE
Accessories belt: Removal - Refitting
K9K, and AIR CONDITIONING
11A
II - REFITTING OPERATION FOR PART
CONCERNED
a Rotate the tensioning roller clockwise using a 16
mm offset wrench.
a Refit a new accessories belt.
a Turn the crankshaft two revolutions clockwise (tim-
ing end) to position the accessories belt correctly.
III - FINAL OPERATION
a Refit:
-the front right-hand wheel arch liner (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection),
-the front right-hand wheel arch side liner,
-the plastic shield underneath the diesel filter,
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres).
101878
