80D-43
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 6
CONTINUED 1
Check for +12 V (when the rear fog lights are requested) on the following connections:
• 9P of component 172 for a right-hand drive vehicle,
• 9P of component 173 for a left-hand drive vehicle,
Check for earth on the following connection:
• MF of component 172 for a right-hand drive vehicle,
• MG of component 173 for a left-hand drive vehicle,
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or Technical
Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise
replace it.
Check the continuity and insulation of the following connections:
• 9J between components 209 and 1016.
• 9P between components 172 and 1016 (for a right-hand drive vehicle),
• 9P between components 173 and 1016 (for a left-hand drive vehicle),
• MF between components 172 and earth (for a right-hand drive vehicle),
• MG between components 173 and earth (for a left-hand drive vehicle),
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
