80D-44
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 6
CONTINUED 2
With the rear fog lights control activated, check for +12 V on connection 9J of the lighting stalk, component code
209.
If not correct, replace the lighting stalk (see MR 451 Mechanical 84A, Control - Signals, - Lighting - signals
switch: Removal - Refitting)
If the fault is still present, contact the Techline.
