80D-49
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 8
CONTINUED 2
For the entry-level version (SOP01)
Check the presence and condition of the supply fuses of the luggage compartment light, component code 165:
• F28 (15 A) on component 1016,
Replace the fuses if the checks are not correct.
Check that the left-hand luggage compartment light, component code 165 is illuminated.
If not, check the condition of the left-hand luggage compartment bulb, component code 165. Replace the left-hand
luggage compartment bulb if necessary (see MR 451 Mechanical, 81B, Interior lighting, Luggage compartment
light: Removal - Refitting).
Check the condition and connection of the connectors of the luggage compartment light, component code 165
and the tailgate lock, component code 1322.
If the connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check for +12 V on the luggage compartment light, component code 165 on the following connection:
• BC of component 165.
Check the continuity and insulation of the following connection:
BC between components 1016 and 165.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
