80D-50
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 8
CONTINUED 3
Check for earth on the tailgate lock, component code 1322 on the following connection:
• MG of component 1322.
If the connection is faulty and there is a repair procedure (see Technical Note 6015A, Electrical wiring repair,
Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Check the continuity and insulation of the following connection:
• 18A between components 165 and 1322
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Check for correct operation of the tailgate lock switch, component code 1322.
Check the continuity between connections 18A and MG of the tailgate lock switch. If not correct, ensure the
conformity of the switch.
If the fault is still present, contact the Techline.
