80D-52
AFTER REPAIR Check the system operation.
V1
MR-453-X79-80D000$120.mif
LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 9
CONTINUED
Check the continuity and insulation of the following connection:
• 65A between components 160 and 639, 172, 173,
If the connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault) or
Technical Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring,
otherwise replace it.
Check for correct operation of the brake lights switch, component code 160.
When the brake lights are requested by the brake pedal, check the continuity between connections AP1 and
65A of the brake lights switch. If it is not correct, ensure the conformity of the switch.
If the fault is still present, contact the Techline.
