LIGHTING
Fault finding – Fault Finding Chart
80D
UCH
Vdiag No.: 09
ALP 10
The brake lights are still illuminated and the brake light switch is
released
NOTES
Only consult this customer complaint after a full check with the diagnostic tool.
There must be no present or stored faults.
Special note:
Use the Wiring Diagrams Technical Note for DUSTER.
Check the condition and connection of the connectors of the brake lights switch, component code 160, the high-
level brake light, component code 639, the rear right-hand light, component code 172, and the rear left-hand light,
component code 173.
If the connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing electrical
wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check the insulation to +12 V feed of the following connection:
• 65A of component 172, 173 and 639.
If the connection or connections are faulty and if there is a repair procedure (see Technical Note 6015A (Renault)
or Technical Note 9804A (Dacia), Electrical wiring repair, Wiring: Precautions for repair), repair the wiring,
otherwise replace it.
If the fault is still present, contact the Techline.
UCH_V09_ALP10
