03B-1
COLLISION
Vehicle involved in an impact: Impact fault finding
03B
a
I - CHECKING THE SUBFRAME
Chronological order of checks
a FRONT impact
Compare the following distances between diagonal-
ly opposite points:
-1: B1 - G2 = B2 - G1
-2: G1 - C2 = G2 - C1
a REAR impact
Compare the following distances between diagonal-
ly opposite points
-1: G2 - B1 = G1 - B2
-2: B1 - J2 = B2 - J1
145391
