82D-41
AFTER REPAIR Carry out a complete check with the diagnostic tool.
V1
MR-453-X79-82D000$170.mif
ACCESS – SAFETY
Fault finding – Fault location chart
82D
UCH
Vdiag No.: 09
ALP 9
CONTINUED 2
Check the battery voltage with the starter motor activated and the + starter supply.
Check the condition of the starter exciter terminal. Repair if necessary.
Check for + 12 V at the starter excitation terminal, when the starter is activated.
Repair if necessary (ignition switch supply, correct operation of the ignition switch and ignition switch/starter
connection).
If the fault is still not resolved, check that the starter motor is operating correctly. Replace the starter if necessary
(see MR 451, Mechanical, 16A, Starting - Charging, Starter: Removal - Refitting).
B
