AFTER REPAIR Carry out a complete check with the diagnostic tool.
V1
MR-453-X79-82D000$170.mif
ACCESS – SAFETY
Fault finding – Fault location chart
82D
UCH
Vdiag No.: 09
ALP 9
CONTINUED 3
Check the battery voltage when the starter is turning and check the earth straps connecting the engine and
transmission assembly to the vehicle chassis.
Check the continuity, insulation and absence of interference resistance on the following connections:
• B between components 163 and 107,
• D between components 107 and 104.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Check that the starter motor has not seized or locked.
If the fault is still present, replace the starter (see MR 451 Mechanical, 16A, Starting - Charging, Starter:
Removal - Refitting).
C
