82D-46
AFTER REPAIR Carry out a complete check with the diagnostic tool.
V1
MR-453-X79-82D000$170.mif
ACCESS – SAFETY
Fault finding – Fault location chart
82D
UCH
Vdiag No.: 09
ALP 12 The electric door locking/unlocking control operates erratically
NOTES
Only refer to the customer complaints after performing a complete check using
the diagnostic tool.
Use the Wiring Diagrams Technical Note for DUSTER.
Check the connection and condition of the UCH connector, component code 645 and check the electric door
locking control connector, component code 123.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
For locking:
Check the continuity and the insulation of the following connections:
• 20A between components 123 and 645,
• MAN between components 123 and earth.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
For unlocking:
Check the continuity and the insulation of the following connections:
• 20B between components 123 and 645,
• MAN between components 123 and earth.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
If the fault is still present, contact the Techline.
UCH_V09_ALP12
