11A-30
TOP AND FRONT OF ENGINE
Timing belt: Removal - Refitting
K4M
11A
a Refit:
-the right-hand suspended engine mounting (see
19D, Engine mounting, Right-hand suspended
engine mounting: Removal - Refitting, page
19D-4) ,
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-2) ,
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres),
-the air resonator (see 12A, Fuel mixture, Air res-
onator: Removal - Refitting, page 12A-2) ,
-the air inlet duct.
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
