11A-65
TOP AND FRONT OF ENGINE
Camshaft seal, timing end: Removal - Refitting
K9K
11A
a Screw on the collar nut until the cover touches the
cylinder head.
2 - Second fitting of the camshaft seal
a Depending on the case, the Parts Department deliv-
ers seals (15) equipped with a spacer (16) amongst
other things.
a
21687-3
123076
123075
Note:
The spacer (17) is used to fit the seal (18) and is
used in addition to the tool (19) .
