13A-12
FUEL SUPPLY
Fuel flow: Check
K4M
13A
a Connect:
-the « T » union (Mot. 1311-08) (6) to the fuel tank
outlet pipe,
-the pipe (5) contained in the test kitonto the « T »
union (6) ,
-the fuel supply pipe (7) to the « T » union (6) .
a Insert the pipe (11) into a graduated measuring cyl-
inder (2000 ml).
a Remove the Protection and Switching Unit cover.
a Disconnect the connector (12) from the passenger
compartment engine harness.
109173
109174
116568
