16A-7
STARTING - CHARGING
Alternator: Removal - Refitting
K4M, and STANDARD HEATING RECIRCULATION
16A
REFITTING
I - REFITTING PREPARATION OPERATION
a Push the rings (10) to make fitting easier.
II - REFITTING OPERATION
a Refit the alternator.
a Torque tighten the alternator bolts (21 N.m).
III - FINAL OPERATION
a Connect the alternator electrical connections.
a Torque tighten the positive terminal nut on the al-
ternator (14 N.m).
a Connect the fuel supply pipe union on the injector
rail.
a Refit:
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-2) ,
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres).
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
18987
