10A-8
ENGINE AND CYLINDER BLOCK ASSEMBLY
Crankshaft seal, gearbox end: Removal - Refitting
K4M or K9K
10A
a Remove the nut, the cover, the protector and the
base plate.
a Refit the crankshaft seal at the gearbox end, using
the tool (14) .
III - FINAL OPERATION
a Refit:
- the flywheel (see 10A, Engine and cylinder block
assembly, Flywheel: Removal - Refitting, page
10A-75) (20A, Clutch),
- the clutch (see Pressure plate - Disc: Removal -
Refitting) (20A, Clutch),
- the gearbox (see Manual gearbox: Removal - Re-
fitting) (21A, Manual gearbox).
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
a Perform the following operations:
- fill the manual gearbox (see Manual gearbox oils:
Draining - Filling) (21A, Manual gearbox),
- bleed the clutch control circuit (see Clutch circuit:
Bleed) (37A, Mechanical component controls).
20764
20765
K4M
134544
