19C-4
TANK
Fuel tank: Removal - Refitting
4X2 TRANSMISSION
19C
a Remove the body earth cable at (2) . a Remove the oxygen sensor connector by sliding it
from its support (in the direction of the arrow).
a Disconnect the oxygen sensor connector.
a Remove:
- the heat shield pins (4) ,
- the fuel tank heat shield.
K4M
109185
K4M
108424
109183
