19C-5
TANK
Fuel tank: Removal - Refitting
4X2 TRANSMISSION
19C
a Remove the catalytic converter mountings (6) on the
exhaust manifold.
a Detach the exhaust line assembly on the left-hand
side.
a Attach the front section of the exhaust line assembly
to the front lower arm on the left-hand side.
a Remove the exhaust pipe mountings (8) from the
catalytic converter.
a Place the exhaust line assembly on the left-hand
side.
a Attach the front section of the exhaust line assembly
to the front lower arm on the left-hand side.
a Unclip the parking brake cables from:
- the fuel tank,
- on the body.
K4M
116557
K9K
114121
