19C-6
TANK
Fuel tank: Removal - Refitting
4X2 TRANSMISSION
19C
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Remove the bolts (9) from the filler neck.
a Disconnect the snap-on unions (10) from the tank
outlet pipes.
a Remove the external fuel filter (if fitted to the vehicle)
(see Fuel filter: Removal - Refitting) .
a
a Remove the bolts (11) from the fuel tank.
a Lower the tank slightly.
a Remove the fuel tank.
REFITTING
I - REFITTING PREPARATION OPERATION
a It is essential to replace the sealing ring between the
exhaust manifold and the catalytic converter.
II - REFITTING OPERATION FOR PART
CONCERNED
a
118344
108650
109181
Note:
This operation requires two people.
109399
Note:
This operation requires two people.
