19C-7
TANK
Fuel tank: Removal - Refitting
4X2 TRANSMISSION
19C
a Refit the fuel tank.
a Refit the fuel tank bolts.
a Torque tighten the fuel tank bolts (21 N.m).
a Refit the external fuel filter (if fitted to the vehicle)
(see Fuel filter: Removal - Refitting) .
a Reconnect the snap-on unions to the tank outlet fuel
pipes.
a Refit the filler neck bolts.
III - FINAL OPERATION
a Clip the parking brake cables:
-onto the body,
-onto the fuel tank.
a Refit the exhaust system assembly onto the catalytic
converter.
a Torque tighten the exhaust pipe bolts on the cata-
lytic converter (21 N.m).
a Refit the exhaust system assembly onto the exhaust
manifold.
a Torque tighten the catalytic converter bolts on the
exhaust manifold (21 N.m).
a Connect the oxygen sensor connector.
a Refit:
-the oxygen sensor connector to its support,
-the earth cable on the body.
a Torque tighten the earth cable nut on the body (8
N.m).
a Refit:
-the fuel tank heat shield,
-the heat shield pins.
a Reconnect the fuel level sensor module connector.
a Refit the access flap for the fuel level sensor module
on the floor.
a Refit the rear bench seat base (see ) (76A, Rear
seat frames and runners).
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
K9K
K4M
