19C-9
TANK
Fuel level sensor module: Removal - Refitting
K4M or K9K
19C
a Disconnect:
-the connector (3) ,
-union (4) .
a Remove the nut from the fuel level sensor module
using the tool (Mot. 1397) (5) ,
a Let the fuel drain from the fuel level sensor module.
a Remove:
- the fuel level sensor module, taking care not to
damage the float,
- the fuel level sensor module seal.
REFITTING
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: Fuel level sensor
module nut
a parts always to be replaced: Fuel level sensor
module seal
K4M
144825
109176
WARNING
To prevent the tank from deforming, refit the fuel
sender unit nut to the tank well immediately.
