21A-13
MANUAL GEARBOX
Manual gearbox: Removal - Refitting
K4M, and JR5
21A
a Disconnect the reverse gear connector (6) .
a Remove:
- the earth strap bolts (7) on the gearbox,
-the bolt (8) from the power-assisted steering pipe
on the gearbox,
-the bolt (9) from the power-assisted steering pipe
on the gearbox mounting,
- the bolt (10) from the power-assisted steering pipe
on the subframe.
141720 24766
24762
