29A-10
DRIVESHAFTS
Front driveshaft gaiter, wheel side: Removal - Refitting
JR5
29A
Position 1 - Pre-tightening and positioning of the
clip
a Put the linkage (17) in the lower position, and close
the pliers fully. The pre-tightened clip slides onto the
gaiter and can be positioned.
Position 2 - Tightening
a Put the linkage (17) in the upper position, and close
the pliers fully.
III - FINAL OPERATION
a Refit the driveshaft on the side concerned (see 29A,
Driveshafts, Front right-hand driveshaft: Remov-
al - Refitting, page 29A-4) or (see 29A, Drive-
shafts, Front left-hand driveshaft: Removal -
Refitting, page 29A-1) .
2911
2912
